The box from the store is sitting on the pontoon’s front deck, the kids are already in their life jackets, and Dad is walking the rail looking for somewhere to tie the straps. That’s the moment most people discover whether their slide really fits. A few minutes of checking before you buy saves that scramble. This page is the boat slide compatibility check for the three places slides go: pontoons, yachts and docks.

In short: a slide fits when its starting height matches your deck, it attaches to structural points and every rider is within the maker’s limit. Pontoon slides are sold for “most” pontoons with a 200 lb rider limit and strap to the boat; yacht slides are sized to your rail-to-waterline drop and sit 10 to 15 cm above the rail on FunAir models; dock slides depend on the dock’s height and the water under it.

Boat slide compatibility: the quick checklist

Check	Pontoon	Yacht	Dock
Starting height	Deck and rail at the bow or side gate	Rail-to-waterline drop, measured loaded	Dock surface above the water
How it’s sized	One size, “fits most pontoon boats”	By drop bands (FunAir, Yachtbeach) or custom	By dock height
Attachment	Straps to the boat’s structure	Anchor points and rigging; lifting bridles on big slides	Straps or mounting to the dock frame
Rider limit	200 lb, one rider (makers)	Ask the maker; rarely published	200 lb on the slides we list
Water depth	RAVE: at least 5 ft	Open water at anchor	Check the maker; see our depth guide

Pontoon boats

Pontoons are the easiest boats to fit a slide to, which is why most consumer slides are built for them. The flat deck and the gate in the rail give a slide somewhere to sit, and the low deck means a short climb. Still, “most pontoons” isn’t “every pontoon.”

Size. Published pontoon slides are similar in size: the RAVE Pontoon Slide is 10 ft long, 25 in wide and 68 in high with a 9 ft slide; the Airhead Spillway is 10.5 x 2.75 x 4.5 ft with an 8 ft sliding surface; the O’Brien is 105 in long and 70 in high. Look at your bow or side deck and check there’s room for the ladder end and a clear path off the side.

Rider limit. RAVE, Airhead, WOW, O’Brien and the discontinued Aquaglide Freefall all state 200 lb per rider. WOW says one rider. That rules out many adults on some slides; there’s no maker that rates a pontoon slide higher in our catalog. If your family has riders over 200 lb, look at our inflatable boat slides guide for different designs.

Attachment. RAVE’s listing says to attach the slide “to pontoon sides with included straps”; WOW uses adjustable straps and O’Brien heavy-duty anchor straps. Where those straps go matters. A retailer’s guide puts it well: the slide “should attach to structural points on the boat, not to a railing that was designed to stop people leaning,” and if you’re not sure whether your rail bases are through-bolted with backing plates, ask whoever services the boat. Follow the strap points in your slide’s instructions; if your boat doesn’t have suitable ones, ask your dealer before you improvise.

Power and pumps. RAVE includes a 12V high-pressure inflator that runs off the pontoon’s battery. The Spillway has no pump; it uses a Halkey Roberts-type high-pressure valve, so you’ll want a 12V pump with that adapter.

Prices seen on Amazon in October 2026: RAVE about $320, Spillway about $605, Airhead pump about $72. The pump’s listing says its release valve stops filling at 1.4 psi; check the pressure your slide’s manual asks for.

Double-decker pontoons. Some pontoons come with an upper deck and a factory slide, like Bennington’s Top Deck option. Those slides are part of the boat, so the question is which model to buy, not what fits. See pontoons with slides.

Yachts

On a yacht, the fit question is mostly answered by the measurement. Makers size from the rail-to-waterline drop (see how to measure it), then check the deck layout and rigging.

Rail clearance. FunAir’s answer to “will it damage my handrails?” is that its slides “sit 10–15 cm above the rails, ensuring there is no direct contact, stress, or pressure on them.” That’s 4 to 6 in of clearance, so check there’s nothing just above the rail where the slide will lie, such as a canopy edge or a light.

Anchor points. “Proper anchor points and rigging are essential,” says FunAir, and it plans them during design. Superyacht Tenders & Toys fits lifting bridles so a crane or davit can lift its bigger slides into place. Yachtbeach’s 4.6 attaches to a swim platform, a railing or a Yachtbeach platform.

Deck space and crew. Small QuickShip slides (FunAir FunSize and Hanger Mini) are handled by 1 or 2 crew in under 15 minutes, per the maker. The Yachtbeach 6.2 and 7.2 weigh about 116 and 120 kg and need 2 crew. The custom FunAir Riser takes about 60 minutes. Make sure there’s room on deck to unroll and inflate, and somewhere to stow the slide afterwards.

Smaller boats. The FunAir FunSize (1.5 m drop, yachts up to 20 m) and the Yachtbeach Mini Side (245 cm high, 300 cm slide) are the smallest yacht-style slides we found. Yacht slides are sold by quote; ask through Request more information and we’ll help you put the right numbers in front of the maker.

Docks

Dock slides go on the end of a dock and run into the lake. The fit question is the dock’s height above the water and what’s underneath. The RAVE Dock Slide, which could strap to a pontoon or stand on a dock, is now discontinued; retailers listed it for docks 12 to 30 in above the water. The Spillway is also sold as a dock slide. Our best dock slides guide covers the current choices, and water depth and clearance covers the landing.

What we can’t tell you

We can’t promise that a slide fits your boat from its dimensions, and we won’t compute a safe load from a slide’s size. The maker’s rider limit and attachment instructions are the rules. No maker publishes a wind limit or a minimum age for boat slides, so any number you see for those isn’t from the maker.

Compatibility questions

Can I put a pontoon slide on a bowrider or deck boat?

Pontoon slides are designed and described for pontoon boats. For other boats, see our inflatable boat slides guide, which covers slides made for a swim platform or a stern.

Can I tie the slide to the pontoon rail?

Follow your slide’s instructions. The general advice is to use structural points, not a rail made to stop people leaning; if you’re unsure whether your rail is through-bolted, ask your dealer.

Can two kids go down together?

Pontoon slide makers rate them for one rider at a time up to 200 lb. Take turns.

Do I need a special pump?

Some slides include one (RAVE); some don’t (Spillway). Match the pump’s adapter to the slide’s valve; the Spillway uses a Halkey Roberts-type valve.
